NH1602GN003SG

Character LCD 2.3” 16×2, COG, Without B/L, FSTN white pos, I2C, 6H, Standard Temp., No touch

SKU: NH1602GN003SG Category: MONO LCD DISPLAY

Additional information

Technology	Mono LCD
Size	2.3"
Resolution	16×02
Shape	Rectangular
Constructive Structure	COG
Color	Without B/L, FSTN white pos
Polarizer	Transflective
Interface	I2C
V(LCD) Onboard	na
View Angle	6H
Operating Temperature (°C)	-20°C + 70°C
Display Connection	Pin Strip
Touch Panel	None
Frame	No

Description

Downloads

NH1602GN003SG Specs

1 file(s) 569 KB

Download

Customization

There are a lot of different options of semi-customization:

– Resolution
– Touch panel and optical films
– Frame
– Connectors

For more information about the technology please contact technical@nextvisiondisplay.com
